Re: Dresdon's DF-12 Stainless Steel Jetpack build(see newest post)
« Reply #45 on: Apr 10, 2013, 08:00 PM »
I did look into automotive stuff, but it was way pricier just by application than the faucet hoses.

Also;
I do believe I'm the only one here with a stainless steel jetpack...or at least the first?

« Last Edit: Apr 12, 2013, 08:56 PM by Dresdon Acacin » Logged
Work while they sleep   Learn while they party   Save while they spend   Live like they dream


Kelan Ord


    *
  • *
  • *
  • *
  • *
  • 6166
  • Mando McConaughey
  • Awards 11+ Invasion Report Appearances Legends of Mandalore Brigade Mandalorian Protector Brigade Member Award for 25 official invasions. Order of the Ori'Ramikad
Re: Dresdon's DF-12 Stainless Steel Jetpack build(see newest post)
« Reply #46 on: Apr 12, 2013, 11:37 AM »
Also;
I do believe I'm the first one here with a stainless steel jetpack...or at least the first?

Probably, because people tend to avoid having 100+ pounds kit...  ;)

Logged

Dresdon Acacin


    *
  • *
  • *
  • 3915
  • Do it right the first time or don't do it at all.
  • Awards Celebration Chicago 11+ Invasion Report Appearances Ground Pounder - Official Member with the most recorded invasions Award for 10 official invasions. Shock Infantry Brigade Member
Re: Dresdon's DF-12 Stainless Steel Jetpack build(see newest post)
« Reply #47 on: Apr 12, 2013, 11:42 AM »
actually, im replacing the angleiron frame with 1/4" aluminum soon. Just got some commision work that gets first priority.

Logged
Work while they sleep   Learn while they party   Save while they spend   Live like they dream


Dresdon Acacin


    *
  • *
  • *
  • 3915
  • Do it right the first time or don't do it at all.
  • Awards Celebration Chicago 11+ Invasion Report Appearances Ground Pounder - Official Member with the most recorded invasions Award for 10 official invasions. Shock Infantry Brigade Member
Re: Dresdon's DF-12 Stainless Steel Jetpack build(see newest post)
« Reply #48 on: Apr 12, 2013, 09:18 PM »
Probably, because people tend to avoid having 100+ pounds kit...  ;)
I'm sure I could tranfer to a set of beskar armour with little to no transition period.

Oh and here is the circuit I made for it, had this installed just before my last event but had projects galore so I couldnt update my threads just yet.



this was very tricky to make due to my giant 140W Weller 8200 soldering gun rated for like......stained glass work  :o


« Last Edit: Jul 13, 2013, 02:12 AM by Dresdon Acacin » Logged
Work while they sleep   Learn while they party   Save while they spend   Live like they dream


Karvas Dral


    *
  • 1245
  • Poodoo.
Re: Dresdon's DF-12 Stainless Steel Jetpack build(see newest post)
« Reply #49 on: Apr 13, 2013, 11:50 AM »
Dude, you are such a jawa!  :P
What is that? What's it gonna do?

ConDar Ward


    *
  • *
  • *
  • *
  • *
  • *
  • 7886
  • Al'jurir be Ori'ramikad
  • Awards Order of the Ori'Ramikad Clan with the most recorded invasions in 2016/2017 Clan with the largest number of new OM's in 12 months Award for 10 official invasions. Celebration Orlando 2017
Re: Dresdon's DF-12 Stainless Steel Jetpack build(see newest post)
« Reply #50 on: Apr 13, 2013, 11:55 AM »
Dude, you are such a jawa!  :P
What is that? What's it gonna do?


ROFL    :P :P :P


It's a thingamabob for his Doohjicky ... Read Back <   :rolleyes:

Logged

MMCC-#0059 /M.A.- 001 /M.A.D.- 067 /ALUMINATI -013
 Ni su'cuyi, gar kyr'adyc, ni partayli, gar darasuum - Remo Jadd - 0267

Dresdon Acacin


    *
  • *
  • *
  • 3915
  • Do it right the first time or don't do it at all.
  • Awards Celebration Chicago 11+ Invasion Report Appearances Ground Pounder - Official Member with the most recorded invasions Award for 10 official invasions. Shock Infantry Brigade Member
Re: Dresdon's DF-12 Stainless Steel Jetpack build(see newest post)
« Reply #51 on: Apr 13, 2013, 02:24 PM »
Gonna make a mini vid about it tonight.

Logged
Work while they sleep   Learn while they party   Save while they spend   Live like they dream


Dresdon Acacin


    *
  • *
  • *
  • 3915
  • Do it right the first time or don't do it at all.
  • Awards Celebration Chicago 11+ Invasion Report Appearances Ground Pounder - Official Member with the most recorded invasions Award for 10 official invasions. Shock Infantry Brigade Member
Re: Dresdon's DF-12 Stainless Steel Jetpack build(see newest post)
« Reply #52 on: Apr 16, 2013, 07:05 AM »
busted the comm spike light that night-repaired it and added another batt. container then filmed, but the vid is still on my dad's Iphone -.-


In other news, my mind is filled with vipers wispering 'rebuild' for a Mk.5 Dresdon Acacin.

Maybe I'll get these...
http://www.dynotunenitrous.com/store/scripts/prodView.asp?idproduct=92
I'm at school atm so I don't know if this will fit inside my jetpack off the top of my head, but if it does then I'll be using this bigger bottle for it
http://www.dynotunenitrous.com/store/scripts/prodView.asp?idproduct=384




This is just awesome and incredible work.
For someone who is new to these boards, i have seen and heard a lot of mention of blackwash, but your toothpaste technique I've is intriguing.
Could someone oblige and explain how to perform these two processes; materials needed, application and what not.
I have an idea of how both methods where used, but its always great to hear others explain how they did it step by step.
Learning from multiple sources is great.
Actualy, I used to use proffesional $20/bottle latex masking fluid, but then I got really poor again  :(

I swear, people insert posts between the cracks


1)silver basecoat(can be bare metal or painted silver))steel and painted both need generous clearcoat))

2)apply toothpaste to all areas to be weathered, were armour-meets-armour, between armour paltes, all raised surfaces, leading edges, random areas, 'critical' areas(blaster fire)

3)Do rest of painting on piece

4)let paint FULLY CURE(average of 3 days to gas out so it's not soft)

5)use course bristled plastic brush, plastic fork, or sandpaper to remove paitn and masking fluid(what you use to remove it can depend on the material the part is made of)

6)generously coat with black acrylic paint and let dry

7)400 grit wetsand to remove  excess black to desired effect.

8)flatt or matt clearcoat MISTED on to seal in weathering and protect paint layers a bit

« Last Edit: Apr 16, 2013, 07:34 AM by Dresdon Acacin » Logged
Work while they sleep   Learn while they party   Save while they spend   Live like they dream


Re: Dresdon's DF-12 Stainless Steel Jetpack build(see newest post)
« Reply #53 on: Apr 16, 2013, 09:03 AM »
Thanks, this is extremely helpful.  ;D

Logged
"It is the unknown that strikes the greatest fear.  The Darkness and Shadows are my strongest Blade."
 - Korhan Ondar

Lando

Re: Dresdon's DF-12 Stainless Steel Jetpack build(see newest post)
« Reply #54 on: Apr 17, 2013, 09:46 PM »
Great build

Logged

Remo Jadd


    *
  • *
  • *
  • *
  • *
  • 7951
  • Vok'Chi Warmaster
  • Awards 267th Rapid Assault Heed the Call - helped the MMCC at a Star Wars Celebration Award for 10 official invasions. Order of the Ori'Ramikad
Re: Dresdon's DF-12 Stainless Steel Jetpack build(see newest post)
« Reply #55 on: May 13, 2013, 10:44 AM »
I do hope you can stand up in all this  :P  :laugh: .

Nice work though ;) .

Dresdon Acacin


    *
  • *
  • *
  • 3915
  • Do it right the first time or don't do it at all.
  • Awards Celebration Chicago 11+ Invasion Report Appearances Ground Pounder - Official Member with the most recorded invasions Award for 10 official invasions. Shock Infantry Brigade Member
Re: Dresdon's DF-12 Stainless Steel Jetpack build(see newest post)
« Reply #56 on: May 13, 2013, 05:43 PM »
8 hours with it all at freecomicbookday and the rotary blaster so that's 150 total.

Logged
Work while they sleep   Learn while they party   Save while they spend   Live like they dream


Dresdon Acacin


    *
  • *
  • *
  • 3915
  • Do it right the first time or don't do it at all.
  • Awards Celebration Chicago 11+ Invasion Report Appearances Ground Pounder - Official Member with the most recorded invasions Award for 10 official invasions. Shock Infantry Brigade Member
Re: Dresdon's DF-12 Stainless Steel Jetpack build(see newest post)
« Reply #57 on: Oct 06, 2013, 08:42 PM »
WEARABILITY UPGRADE!

I splurged and spent an exorbant amount of cash on brass quick disconnect fittings for the hoses, then I had to go get some steel pipe fittings because I was feeling cheap due to the fittings being in 3/4"standard pipe threading and the hose being 1/2" standard pipe threading, they had a coupling in brass that changed that but it would have costed me about $25 for all four(times two)  :o and with the $ dished out for the disconect fittings I wasn't spending like $12/fitting and $6per adaptor for a total of around $100 with tax for the fittings aparatus. So heres what I did...



Parts used:(and Loctite automotive grade threadlock)

I also used the brass nipples(hahahahahaha) already attached to the jetpack that the hoses connect to, those screw into the zinc hose base on the sides of the jetpack, its technicaly a piece of controls/conduit but 1/2" conduit threading is 1/2" pipethreading.

After chopping the steel pipe fittings and shortening the threaded portion, I was left with this on the hose:


Then I realised I needed 2 sets of fittings, so I just ground off the threading on the jetpack part of the disconnect fittings and put the brass nipple in that and brazed it on with some SilFos. After that I used a 120grit sanding wheel to smooth off the SilFos and flux where I brazed, then cleaned them off with a wirebrush to clean off the burnt gasket.


Looks pretty much seamless(and again i used an exorbant amount of threadlock to make sure it stays in place)


this is the part that goes onto the jetpack


and there ya have it.

Oh and the adde 2" on the hoses is a huge improvement on mobility!

Logged
Work while they sleep   Learn while they party   Save while they spend   Live like they dream


Dresdon Acacin


    *
  • *
  • *
  • 3915
  • Do it right the first time or don't do it at all.
  • Awards Celebration Chicago 11+ Invasion Report Appearances Ground Pounder - Official Member with the most recorded invasions Award for 10 official invasions. Shock Infantry Brigade Member
Re: Dresdon's DF-12 Stainless Steel Jetpack build(see newest post)
« Reply #58 on: Oct 12, 2013, 10:46 PM »
Its rather difficult no to doublepost is no one posts inbetween my upgrades....

this upgrade is all about:
METALSTORM!!!


So basicaly, there are two spring-up METALSTORM launchers on the jetpack headboard at either shoulder. I was originaly going to abase them off like those lamps designed like the human arm withthe two bars and then the springs so it can move and pivot n stuff. Originaly it was going to be more complex, but then these ktichen cabinet snap-hinges took most of that ouut of the equation. As for the actual launchers, a couple months back I took apart a VFD drive and god two aluminum terminal blocks out of it and I inteded to use them for exactly this. Im going to add "laser sights" to them consisting of 5mm red LEDs sitting in the backs of some tubes. Might make them tonight, might make a seperate blinking chip for faster rate of blinking for armed light, idk yet.

Heres the snap-hinge and square tube aparatus, i used fancy hex machien screws and a random Tbolt I got from some surveying equiptment i took apart a couple years back. I used the spring from the lamp to keep it in the forwards position and to also make it snap down easier. It will be mounted on either side of the jetpack here:



Here is the actual launcher portion-its the aluminum terminalblock about 1.5"x1.5"x3.5"

How this attaches is there is the open area int eh termianl block. The square tube fits in that hole(loosely) so i drilled through the block to put a 1/4" bolt and a fancy grade7 nut since it looked fancy(although I don't really need a nut rated for like 2 tons on this it makes it better because I say so)


Here is what they look like assembled.

I decided to add some heatsinks onto the square tube ebcause i thought it looked kind of bare...
I also epoxied pieces of sheetmetal on to cover the gaps where one would access the lugnuts on the terminal block.


added those bolts onto the back to cover where the main IN lead would ahve gone into the 'blocks



This demonstrates how the mecahnism acts when its "unfolded" in the upwards position.


most of the device will be black, minus the heatsinks i think...althought I'll be painting it like my blaster, with the silver drybrushed weathering. So i might leave the heatsink bare aluminum...
